Product Summary

The ADUC848BS62-3 is a 24-/16-Bit ADC with Embedded 62 kB Flash and Single-Cycle MCU. It has some applications: Multichannel sensor monitoring, industrial/environmental instrumentation, weigh scales, pressure sensors, temperature monitoring, portable instrumentation, battery-powered systems and data logging, precision system monitoring.

Parametrics

ADUC848BS62-3 abosolute maximum ratings: (1)AVDD to AGND: –0.3 V to +7 V; (2)AVDD to DGND: –0.3 V to +7 V; (3)DVDD to DGND: –0.3 V to +7 V; (4)DVDD to DGND: –0.3 V to +7 V; (5)AGND to DGND1: –0.3 V to +0.3 V; (6)AVDD to DVDD: –2 V to +5 V; (7)Analog Input Voltage to AGND2: –0.3 V to AVDD + 0.3 V; (8)Reference Input Voltage to AGND: –0.3 V to AVDD + 0.3 V; (9)AIN/REFIN Current (Indefinite): 30 mA; (10)Digital Input Voltage to DGND: –0.3 V to DVDD + 0.3 V; (11)Digital Output Voltage to DGND: –0.3 V to DVDD + 0.3 V; (12)Operating Temperature Range: –40℃ to +125℃; (13)Storage Temperature Range: –65℃ to +150℃; (14)Junction Temperature: 150℃; (15)θJA Thermal Impedance (MQFP): 90℃/W; (16)θJA Thermal Impedance (LFCSP): 52℃/W.

Features

ADUC848BS62-3 features: (1)High resolution Σ-Δ ADCs; (2)Two independent 24-bit ADCs on the ADuC845; (3)Single 24-bit ADC on the ADuC847 and single 16-bit ADC on the ADuC848; (4)Up to 10 ADC input channels on all parts; (5)24-bit no missing codes; (6)22-bit rms (19.5 bit p-p) effective resolution; (7)Offset drift 10 nV/℃, gain drift 0.5 ppm/℃ chop enabled.
