The 74AC00SCX is a Quad 2-Input NAND Gate.
Parametrics
74AC00SCX absolute maximum ratings: (1)Supply Voltage (VCC):-0.5V to +7.0V; (2)DC Input Diode Current(IIK): VI=-0.5V:-20 mA, VI=VCC+0.5V:+20mA; (3)DC Input Voltage (VI):-0.5V to VCC + 0.5V; (4)DC Output Diode Current(IOK): VO=-0.5V:-20 mA, VO=VCC+0.5V:+20mA; (5)DC Output Voltage (VO):-0.5V to VCC + 0.5V; (6)DC Output Source or Sink Current (IO):±50 mA; (7)DC VCC or Ground Current per Output Pin (ICC or IGND):±50 mA; (8)Storage Temperature (TSTG):-65℃ to +150℃; (9)Junction Temperature (TJ):PDIP:140℃.
Features
74AC00SCX features: (1)ICC reduced by 50%; (2)Outputs source/sink 24 mA; (3)ACT00 has TTL-compatible inputs.
