Product Summary

The 74AC32SJX contains four, 2-input OR gates.

Parametrics

74AC32SJX absolute maximum ratings: (1)Supply Voltage (VCC): -0.5V to +7.0V; (2)DC Input Diode Current (IIK), VI= -0.5V: -20 mA; VI= VCC + 0.5V: +20 mA; (3)DC Input Voltage (VI) -0.5V to VCC + 0.5V; (4)DC Output Diode Current (IOK), VO = -0.5V: -20 mA; VO = VCC + 0.5V: +20 mA; (5)DC Output Voltage (VO) -0.5V to VCC + 0.5V; (6)DC Output Source or Sink Current (IO): ±50 mA; (7)DC VCC or Ground Current per Output Pin (ICC or IGND): ±50 mA; (8)Storage Temperature (TSTG): -65℃ to +150℃; (9)Junction Temperature (TJ)PDIP: 140℃.

Features

74AC32SJX features: (1)ICC reduced by 50% on 74AC only; (2)Outputs source/sink 24 mA; (3)ACT32 has TTL-compatible inputs.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
74AC32SJX
74AC32SJX

Fairchild Semiconductor

Gates (AND / NAND / OR / NOR) Quad 2-Input OR Gate

Data Sheet

0-1: $0.33
1-25: $0.22
25-100: $0.19
100-250: $0.17
