Product Summary

The AD820A is a precision, low power FET input op amp that can operate from a single supply of +3.0 V to 36 V, or dual supplies of ±1.5 V to ±18 V. It has true single supply capability with an input voltage range extending below the negative rail, allowing the AD820A to accommodate input signals below ground in the single supply mode.

Parametrics

AD820A absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Internal Power Dissipation, Plastic DIP (N): 1.6 Watts, SOIC (R): 1.0 Watts; (3)Input Voltage: (+VS + 0.2 V) to – (20 V + VS); (4)Output Short Circuit Duration: Indefinite; (5)Differential Input Voltage: ±30 V; (6)Storage Temperature Range (N): –65℃ to +125℃; (7)Storage Temperature Range (R): –65℃ to +150℃; (8)Operating Temperature Range, AD820A/B: –40℃ to +85℃; (9)Lead Temperature Range(Soldering 60 sec): +260℃.

Features

AD820A features: (1)Output Swings Rail-to-Rail; (2)Input Voltage Range Extends Below Ground; (3)Single Supply Capability from +3 V to +36 V; (4)Dual Supply Capability from ±1.5 V to ±18 V; (5)Capacitive Load Drive Up to 350 pF; (6)Minimum Output Current of 15 mA; (7)800 μA Max Quiescent Current; (8)Unity Gain Bandwidth: 1.8 MHz; (9)Slew Rate of 3.0 V/μs; (10)800μV Max Input Offset Voltage; (11)1 μV/℃ Typ Offset Voltage Drift; (12)25 pA Max Input Bias Current.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD820AN
AD820AN
Analog Devices Inc
IC OPAMP FET R-R LP 8-DIP
Data Sheet
1-100: $1.60
AD820ANZ
AD820ANZ

IC OPAMP JFET R-R 1.8MHZ LP 8DIP
Data Sheet
0-1: $2.72
1-10: $2.43
10-25: $2.19
25-100: $1.99
100-250: $1.80
250-500: $1.61
500-1000: $1.36
1000-2500: $1.30
AD820AR
AD820AR

IC OPAMP JFET R-R 1.8MHZ 8SOIC
Data Sheet
0-98: $2.48
AD820ARMZ
AD820ARMZ

IC OPAMP FET-IN R-R LP 8MSOP
Data Sheet
0-1: $2.66
1-10: $2.38
10-25: $2.14
25-100: $1.95
100-250: $1.76
250-500: $1.58
500-1000: $1.33
1000-2500: $1.27
AD820ARMZ-R7
AD820ARMZ-R7

IC OPAMP R-R FET-IN LP 8MSOP
Data Sheet
0-1000: $1.33
AD820ARMZ-RL
AD820ARMZ-RL

IC OPAMP R-R FET-IN LP 8MSOP
Data Sheet
0-3000: $1.27
AD820AR-REEL
AD820AR-REEL

IC OPAMP JFET R-R 1.8MHZ 8SOIC
Data Sheet
0-2500: $1.47
AD820AR-REEL7
AD820AR-REEL7

IC OPAMP JFET R-R 1.8MHZ 8SOIC
Data Sheet
0-750: $1.65
